產品描述

海德瑞克 不壓井設備以其高性能和多功能性在全球贏得了聲譽。我們的快速裝配主要是由于輕巧而緊湊的設計，以及防止“破壞”油井。新創新設計包括組合拆分閥芯四通再生控制閥，用于更順暢，更精準的控制設備和新設計的6600英尺雙轉子電機。設備可用于短行程配置，可在任何井口壓力或井口高度下進行操作，以及用于增加管道運行速度的長行程配置。

海德瑞克不壓井設備的設計可以滿足您的不壓裂和液壓修井要求。根據您的規格定制的設備組有全系列的輔助配件，如工作窗口容量達600,00lbs，高壓旋轉循環接頭的工作壓力高達15,000 PSI，以及橇裝泥漿泵包。HRS 150和225設備可用于直升機運輸?shù)倪h(yuǎn)程操作�？商峁〥NV和BP200認證。

Snubbing Unit

Description

HydraRig snubbing units have earned a reputation worldwide for high performance andversatility in the field. Our fast rig up is due to the lightweight, compactdesign and the elimination of the need to “kill” the well. The latest designinnovations include the combination split spool four way regeneration controlvalve for smoother, more precise unit control and the newly designed 6,600ft.lbs dual motor rotary. Units are available in the short stroke configuration tooperate at any wellhead pressure or wellhead height, and the long strokeconfiguration for increased tubing running speed.

Oursnubbing units are designed to meet your snubbing and hydraulic workoverrequirements. Custom packages built to your specifications are available with afull line of auxiliary components such as work windows up to 600,00lbscapacity, high pressure circulating swivels up to 15,000 PSI operating pressureand skid mounted mud pump packages. HRS 150 and 225 units are available in helitransportable models for remote operations. DNV and BP200 certification isavailable.

品牌介紹

Hydra Rig海德瑞克是美國NOV國民油井旗下品牌，成立于1973年，專業生產連續油管設備、液氮泵設備等油田設備，以優良的產品品質和客服贏得了廣泛的贊譽。Hydra Rig海德瑞格連續油管車等設備的常用零配件，包括：導向滾柱、法蘭軸承、滾珠軸承、行星齒輪、密封包、排管器馬達、針形閥、芯軸，等等。Hydra Rig是美國NOV國民油井旗下品牌，1973年成立于美國德克薩斯州，專業生產連續油管設備、液氮泵設備,不壓井修井設備和連續油管鉆井設備等油田設備，因其產品的性能和質量?jī)?yōu)良而在全球享譽盛名。
